Let Ventilation&Anesthesia Management More Simple

In the future, we will continue to stay true to our original intention, adhere to ingenuity, and continue to practice the design concept of making respiratory anesthesia easier, promote the upgrading of respiratory anesthesia in China and the world, and let intelligent manufacturing become more and more popular on the world stage.

Product introduction

Feature：

Animal-specific bellows design to meet the needs of clinical scientific research.

Suitable for small animals, Non-breathing circuit(Jackson or Bains Absorber) is available.

Professional airtight breathing circuit design, provide the stable gas anesthesia, save anesthesia gas consumption, to ensure a clean operating room and laboratory environment.

External and reusable soda lime canister, easily watch and replace soda lime.

With Oxygen flush function to ensure that clinical anesthesia demand and Oxygen supply demand.

Anaesthesia CO2 absorber assembly has no dead angle design, fast anesthesia, short recovery and high precision. The CO2 absorber supports both open and close anaesthesia design and provides independent access .

Provide a special Pop-Off valve,Occlusion design, it can connected to the exhaust gas recovery system and provide a continuous 2 cmH2O negative pressure for the reaspirato airbag ,reducing valve to prevent pressure to hurt the animal, ensure the animal safety .

Provides an accurate oxygen flow meter with a display range of 0 to 5LPM

Vaporizer: the output concentration is not affected by the change of flow, pressure and temperature, accurate and reliable, equipped with safety locking device to prevent

anesthetic leakage.

The hard aluminum solid shell is used, and the surface sanding treatment is adopted, so that the cleaning and disinfection are more convenient.

Visible inspiration and expiration valve

With fresh gas output connector ,specifically designed to accomodate low flow

Technical Specification

Vet Main unit
Working mode	Open,Closed,half-closed,half-open
Driving mode	Gas drive
Application	0.5kg-100kg animal
Anesthesia vaporizer	MSS Isoflurane
Fast oxygen flush	25L/min~75L/min
Gas source pressure	Oxygen 0.25Mpa~0.65Mpa
Trolley	High-quality aluminum alloy profile, with storage frame and special interface for exhaust gas emission

CO2 Absorber
Sodium Lime Tank Capacity	500ml-750ml
Absorber	The animal-specific integrated circuit can be sterilized at high temperature and high pressure at 134 ℃. The dedicated interface can be connected to an open circuit, suitable for low-flow small animals.
Valve piece	Visible ceramic valve piece, easy to observe animal breathing.
Pop off valve	Directs the waste anesthetic gas from the machine to a scavenging system. In the completely open position, the pop-off valve will release pressure at 2 cm H2O, while maintain a constant passive volume in the breathing bags.

Anesthesia Vaporizer
Brand	UK MSS
Concentration scope	Isoflurane：0.2%~5%
Flow rate scope	0.2L/min~15L/min
With pressure, flow and temperature automatic compensation function；equipped with safety lock

Configuration
Standard	Main unit ,Oxygen gas supply hose,cylinder pressure regulator,MSS anesthesia vaporizer,Trolley, Animal breathing circuit,Exhaust gas absorption system,Tracheal intubation,Animal anesthesia mask,Anesthesia throato scope,Sodium Lime,Active carbon
Option	Ventilator bracket,Anesthesia ventilator,Non-breathing circuit.
