Space saving compact design

Build-in battery,can continue working in case of power failure

Anesthesias Gas soruce swtith design,keep operation at high efficient

Top-light system

Alloy frame, humanized handle, easily and conveniently move the machine to any place.

Equipped with high precise Anesthesia Vaporizer.(Support Single or two vaporizer)

Adopting stainless pressure gauge, both gas supply and working pressure could be monitored. The pressure range is 0-1MPa, reading scale is 0.05

With special protection device for Power Socket and Standby Power Socket, so as to avoid any accidents;

Audible O2.failure warning device

Four Anti-static castors(2 with brakes)

2 large drawers with big storage space(spport three drawer optional)

Electro-pneumatic ventilator

Common gas outlet(CGO)

Ergonomics design to meet the animal clinical requirements,suit for lab .animal hosptial and scientic institute etc.

Saml animal special bellow design

Product introduction

Main Unit:

Working Mode:Closed,Semi-closed,,semi-open system,Open

Driven mode: Pneumatically driven manual controlled

Application:0.5-100kg animal

Anesthesia gas source switch:start or stop the gas source control

Pressure Gas Gauge:four press gauge;one is oxygen source pressure

one is oxygen working

Alarm parameter:Upper tidal volume alarm,low oxygen alarm,Apnea,Power failure

High precious anesthesia vaporizer,the agent output is continuous and stable, and precise.

 the agent type: Isoflurane, Enflurane,halothane,sevoflurane.

Oxygen flush:25L/min~75L/min

Airway pressure:  O2:0.25Mpa~0.65Mpa

Power:220V±10%,50HZ±1% or 110V±10%,60HZ±1%

Flow meter:

O2 Two tube flowmeter

Two tube:0~1L/min,

  1~10L/min                ,

O2& Air Flowmeter Optioanl

O2&N2O& Air Flowmetr Optiaonl


Circle Absorer:

Integrated and sterilized at 134°C high temperature and high pressure.

Visiable inspiration valve and expiration valve

Safety valve pressure limit:6Kpa

Quick change soda lime system

Good air tightness,high reliability and minor respiratory impedance

Manual/ventilation swith



Anesthesia Ventilator

Small animal bellow design(0-300ml)


Pneumatically driven and electrically controlled

Display:HD LCD digital display

Monitoring:Tidal volume,breathing rate,I:E ratio,Peak airway pressure,


Breathing rate:4~60bpm

I:E ration:1:1~1:4 adjustable

Upper airway pressure:2~6kpa

Lower airway pressure:0.5~2kpa

Battery low alarm

Battery no power indicator

Alarm Silence

Manuel/Auto Switch
