Applied to animals of different weights and sizes
With pressure, volume, manual and other breathing modes, meet different clinical needs
The built-in high-precision sensor and valve control technology ensure the safety, stability and accuracy of pressure, flow and volume monitoring and control
Equipped with high-precision anesthesia vaporizer, three-year warranty
Import of core parts and components from the international origin
Equipped with 8-inch high-definition touch screen
Triple visual and audio security alarm system to ensure safety during surgery
Built-in proportional valve control system
Integrated circuit, easy to install and remove
Dome light system provides better vision for doctors
Built-in battery, can last more than two hours
Just set the weight, other parameters are automatically calculated
Main Unit：
Working Mode：Closed,Semi-closed,，semi-open system，Open
Driven mode: Pneumatically driven manual controlled
Application:0.5-100kg animal
Anesthesia gas source switch:start or stop the gas source control
Pressure Gas Gauge:four press gauge;one is oxygen source pressure
one is oxygen working
Alarm parameter:Upper tidal volume alarm,low oxygen alarm,Apnea,Power failure
High precious anesthesia vaporizer,the agent output is continuous and stable, and precise.
the agent type: Isoflurane, Enflurane,halothane,sevoflurane.
Oxygen flush：25L/min~75L/min
Airway pressure: O2:0.25Mpa~0.65Mpa
Power:220V±10%,50HZ±1% or 110V±10%,60HZ±1%
Flow meter：
O2 Two tube flowmeter
Two tube:0~1L/min,
1~10L/min ,
O2& Air Flowmeter Optioanl
O2&N2O& Air Flowmetr Optiaonl
Circle Absorer:
Integrated and sterilized at 134°C high temperature and high pressure.
Visiable inspiration valve and expiration valve
Safety valve pressure limit:6Kpa
Quick change soda lime system
Good air tightness,high reliability and minor respiratory impedance
Manual/ventilation swith
Anesthesia Ventilator
Vet Anesthesia ventilator | |
Respiration mode | PCV,VCV,SPONT,DEMO |
Bellow | Big animal t:50-1600ml,small animal:0-300ml |
Screen | 9 inches touch screen |
Waveform | Pressure,Flow,Volume |
Loop | PV,PF,FV |
Tidal volume | Mechanical control：20-1600ml |
Manual control：5-1600ml | |
BPM | 1-100bpm |
I：E | 9.9：1to1:9.9 |
Inspiratory time | 0.1s-10.0s |
Apnea | 0-50% |
PEEP | Off,3-20cmH2O |
Pressure support | 5-60cmH2O |
Flow trigger | 0.5-20L/min |
Pressure trigger | -1~20cmH2O |
PSV Inspiratory terminal level | 25% |
Monitoring | Tidal volume,breathing rate,Spontaneous breathing rate,I:E,Spontaneous minute ventilation volume，Minute ventilation peak airway pressure,Average airway pressure,PEEP,Inspiratory platform pressure,FIO2 |
Alarm parameters | Tidal volume,Minute ventilation volume,Frequency,Airway pressure ,Continuous airway pressure,Negative pressure alarm,Apnea alarm,Air supply pressure failure alarm,Power supply alarm,Low battery alarm,Battery exhaustion alarm,Oxygen battery failure alarm,FIO2(optional),FICO2(optional) |
Power supply | 220V±10%,50HZ±1% |
