Main Unit：

Working Mode：Closed,Semi-closed,，semi-open system，Open

Driven mode: Pneumatically driven manual controlled

Application:0.5-100kg animal

Anesthesia gas source switch:start or stop the gas source control

Pressure Gas Gauge:four press gauge;one is oxygen source pressure

one is oxygen working

Alarm parameter:Upper tidal volume alarm,low oxygen alarm,Apnea,Power failure

High precious anesthesia vaporizer,the agent output is continuous and stable, and precise.

 the agent type: Isoflurane, Enflurane,halothane,sevoflurane.

Oxygen flush：25L/min~75L/min

Airway pressure:  O2:0.25Mpa~0.65Mpa

Power:220V±10%,50HZ±1% or 110V±10%,60HZ±1%

Flow meter：

O2 Two tube flowmeter

Two tube:0~1L/min,

  1~10L/min                ,

O2& Air Flowmeter Optioanl

O2&N2O& Air Flowmetr Optiaonl

Circle Absorer:

Integrated and sterilized at 134°C high temperature and high pressure.

Visiable inspiration valve and expiration valve

Safety valve pressure limit:6Kpa

Quick change soda lime system

Good air tightness,high reliability and minor respiratory impedance

Manual/ventilation swith

Anesthesia Ventilator

Small animal bellow design(0-300ml)

(300-2000ml)optional

Pneumatically driven and electrically controlled

Display:HD LCD digital display

Monitoring：Tidal volume,breathing rate,I:E ratio,Peak airway pressure,

TV:50~1600ml

Breathing rate:4~60bpm

I:E ration:1:1~1:4 adjustable

Upper airway pressure:2~6kpa

Lower airway pressure:0.5~2kpa

Battery low alarm

Battery no power indicator

Alarm Silence

Manuel/Auto Switch
